Online Quiz Application

About

This project is an Online Quiz Application designed to enable creating, managing, and taking quizzes featuring various question types such as single choice, multiple choice, and text input.

Built with Node.js, Express, and MySQL (via Sequelize ORM), the application provides a scalable backend API with features including:

• Robust quiz and question management
• Accurate scoring with support for partial credit and negative marking
• Transaction-safe operations ensuring data integrity
• Clear separation of concerns with repository, service, and controller layers
• Comprehensive input validation and global error handling
• Automated tests covering critical functionalities

This system is ideal for educational tools, corporate training, or interactive online quizzes, aiming to deliver a reliable and extensible foundation for quiz platforms.

Important Links

• Database Diagram: Open Database diagram
• SQL Query Runner: RunSql
• Sequence Diagram: Download Sequence Diagram
• Flow Diagram: Download Add Question Flow Diagram
• Flow Diagram: Download Submission Flow Diagram
• Canvas: Download Canvas
• Submission Dryrun Download pdf

Project Setup Guide

Follow these steps to set up the Online Quiz Application project.

1. Fork and Clone the Project

# Fork the project from GitHub
# Then clone it to your local machine
git clone <your_project_url>
cd <your_project_folder>

2. Install Dependencies

npm install

3. Setup Database

Open MySQL and create a database for the project using root or any other user with sufficient privileges.

mysql -u root -p

Enter you password

CREATE DATABASE online_quiz_application_db;

4. Configuration File

• Create a configuration file at src/config/config.json
• configure your database username and password in the development section.

{
  "development": {
    "username": "your-db-username",
    "password": "your-db-password",
    "database": "online_quiz_application_db",
    "host": "127.0.0.1",
    "dialect": "mysql"
  },
  "test": {
    "username": "root",
    "password": null,
    "database": "database_test",
    "host": "127.0.0.1",
    "dialect": "mysql"
  },
  "production": {
    "username": "root",
    "password": null,
    "database": "database_production",
    "host": "127.0.0.1",
    "dialect": "mysql"
  }
}

5. Setup Environment Variables

Create a .env file in the root directory of your project:

PORT=3002
NODE_ENV=development

6. Run Migrations

Go to the src folder and run database migrations:

npx sequelize-cli db:migrate

7. Start the Project

Go back to root Folder and start the project

npm run start

8. Run tests (Optional)

npm run test

Can see the report in the web running test-report.html file

9. Access the Application

Test the application in your web browser | postman:

• Methods: GET
• Endpoint: http://localhost:3002/api/v1/info
• Headers: Content-Type: application/json

{
  "success": true,
  "message": "Api is up",
  "error": {},
  "data": {}
}

Important APIs

1. Create Quiz

• Methods: POST
• Endpoint: /api/v1/quizzes
• Headers: Content-Type: application/json

{
  "title": "Programming Concepts Quiz"
}

{
  "success": true,
  "message": "Quiz created successfully",
  "data": {
    "id": 1,
    "title": "General Knowledge Quiz",
    "createdAt": "2025-10-01T01:00:00.000Z",
    "updatedAt": "2025-10-01T01:00:00.000Z"
  },
  "error": {}
}

2. Create Question

• Methods: POST
• Endpoint: /api/v1/questions
• Headers: Content-Type: application/json

Single choice Question

Request

{
  "quizId": 1,
  "text": "Which keyword is used to define a constant in JavaScript?",
  "type": "single_choice",
  "points": 2,
  "negativePoints": 1,
  "answers": [
    { "text": "let", "isCorrect": false },
    { "text": "const", "isCorrect": true },
    { "text": "var", "isCorrect": false }
  ]
}

Response

{
    "success": true,
    "message": "Question created successfully",
    "data": {
        "id": 2,
        "quizId": 1,
        "text": "Which keyword is used to define a constant in JavaScript?",
        "type": "single_choice",
        "points": "2.00",
        "negativePoints": "1.00",
        "createdAt": "2025-10-01T14:57:30.000Z",
        "updatedAt": "2025-10-01T14:57:30.000Z",
        "answers": [
            {
                "id": 1,
                "text": "let",
                "isCorrect": false
            },
            {
                "id": 2,
                "text": "const",
                "isCorrect": true
            },
            {
                "id": 3,
                "text": "var",
                "isCorrect": false
            }
        ]
    },
    "error": {}
}

Multiple choice Question

Request

{
  "quizId": 1,
  "text": "Which of the following are valid variable names in Python?",
  "type": "multiple_choice",
  "points": 4,
  "negativePoints": 2,
  "answers": [
    { "text": "first_name", "isCorrect": true },
    { "text": "1_variable", "isCorrect": false },
    { "text": "_var", "isCorrect": true },
    { "text": "var_2", "isCorrect": true }
  ]
}

Response

{
    "success": true,
    "message": "Question created successfully",
    "data": {
        "id": 3,
        "quizId": 1,
        "text": "Which of the following are valid variable names in Python?",
        "type": "multiple_choice",
        "points": "4.00",
        "negativePoints": "2.00",
        "createdAt": "2025-10-01T15:02:10.000Z",
        "updatedAt": "2025-10-01T15:02:10.000Z",
        "answers": [
            {
                "id": 4,
                "text": "first_name",
                "isCorrect": true
            },
            {
                "id": 5,
                "text": "1_variable",
                "isCorrect": false
            },
            {
                "id": 6,
                "text": "_var",
                "isCorrect": true
            },
            {
                "id": 7,
                "text": "var_2",
                "isCorrect": true
            }
        ]
    },
    "error": {}
}

Text Input Question

Request

{
  "quizId": 1,
  "text": "What is the typeof value for an array in JavaScript?",
  "type": "text",
  "points": 2,
  "negativePoints": 1,
  "answers": [
    { "text": "object", "isCorrect": true }
  ]
}

Response

{
    "success": true,
    "message": "Question created successfully",
    "data": {
        "id": 4,
        "quizId": 1,
        "text": "What is the typeof value for an array in JavaScript?",
        "type": "text",
        "points": "2.00",
        "negativePoints": "1.00",
        "createdAt": "2025-10-01T15:05:14.000Z",
        "updatedAt": "2025-10-01T15:05:14.000Z",
        "answers": [
            {
                "id": 8,
                "text": "object",
                "isCorrect": true
            }
        ]
    },
    "error": {}
}

3. Get All Question with quizId

• Methods: GET
• Endpoint: /api/v1/questions?quizId=1
• Headers: Content-Type: application/json

Response

{
    "success": true,
    "message": "Questions with answers fetched successfully",
    "data": [
        {
            "id": 2,
            "quizId": 1,
            "text": "Which keyword is used to define a constant in JavaScript?",
            "type": "single_choice",
            "points": "2.00",
            "negativePoints": "1.00",
            "createdAt": "2025-10-01T14:57:30.000Z",
            "updatedAt": "2025-10-01T14:57:30.000Z",
            "answers": [
                {
                    "id": 1,
                    "text": "let"
                },
                {
                    "id": 2,
                    "text": "const"
                },
                {
                    "id": 3,
                    "text": "var"
                }
            ]
        },
        {
            "id": 3,
            "quizId": 1,
            "text": "Which of the following are valid variable names in Python?",
            "type": "multiple_choice",
            "points": "4.00",
            "negativePoints": "2.00",
            "createdAt": "2025-10-01T15:02:10.000Z",
            "updatedAt": "2025-10-01T15:02:10.000Z",
            "answers": [
                {
                    "id": 4,
                    "text": "first_name"
                },
                {
                    "id": 5,
                    "text": "1_variable"
                },
                {
                    "id": 6,
                    "text": "_var"
                },
                {
                    "id": 7,
                    "text": "var_2"
                }
            ]
        },
        {
            "id": 4,
            "quizId": 1,
            "text": "What is the typeof value for an array in JavaScript?",
            "type": "text",
            "points": "2.00",
            "negativePoints": "1.00",
            "createdAt": "2025-10-01T15:05:14.000Z",
            "updatedAt": "2025-10-01T15:05:14.000Z"
        }
    ],
    "error": {}
}

4. Submission

• Methods: POST
• Endpoint: /api/v1/submissions
• Headers: Content-Type: application/json

Request

{
  "quizId": 1,
  "answers": [
    { "questionId": 2, "selectedAnswerId": 2 },
    { "questionId": 3, "selectedAnswerId": [4,6] },
    { "questionId": 4, "textAnswer": "object" }
  ]
}

Response

{
    "success": true,
    "message": "Submission recorded successfully",
    "data": {
        "quizId": 1,
        "totalScore": 8,
        "ScoreObtained": 6.666666666666666
    },
    "error": {}
}

5. List of All available Quizzes

• Methods: GET
• Endpoint: /api/v1/quizzes
• Headers: Content-Type: application/json

Response

{
    "success": true,
    "message": "Quizzes fetched successfully",
    "data": [
        {
            "id": 1,
            "title": "Programming Concepts Quiz",
            "createdAt": "2025-10-01T08:47:44.000Z",
            "updatedAt": "2025-10-01T08:47:44.000Z"
        },
        {
            "id": 2,
            "title": "Shell Scripting quiz",
            "createdAt": "2025-10-01T17:22:31.000Z",
            "updatedAt": "2025-10-01T17:22:31.000Z"
        }
    ],
    "error": {}
}
